Dexter Custom Built 8,000 lb. Narrow Overhang Standard Spring Trailer Axle Beam
Manufacturer: Dexter Trailer Axle
Part #: KT80NXX42F
Halloween Sale! Save 10.7% off this product! Discount auto applied at checkout
This product qualifies for quantity discount pricing
| Quantity | Discount% | Discounted Base Price |
|---|---|---|
| 2-10 | 2% | $529.71 |
| 11-20 | 4% | $518.90 |
| 21-30 | 6% | $508.09 |
| 31-40 | 8% | $497.28 |
| 41-50 | 10% | $486.47 |
| 51-60 | 12% | $475.66 |
| 61-70 | 14% | $464.85 |
| 71-80 | 16% | $454.04 |
| 81-90 | 18% | $443.23 |
| 91+ | 20% | $432.42 |
$9.99 FedEx Flat Rate Shipping Per Order
Made In The USA
107 Years in Trailer Parts Distribution
Frequently Bought With
U-Bolt and Hanger Kit options for 8,000 lbs. Dexter® Axle
Suspension Kit options for 8,000 lbs. Dexter® Axle
Hub options for 8,000 lbs. Dexter® Torflex® Torsion Axle
Hub and drum options for 8,000 lbs. Dexter® Axle
electric backing plate options for 8,000 lbs. Dexter® Axle
Hydraulic backing plate options for 8,000 lbs. Dexter® Axle
Hydraulic disc brake options for 8,000 lbs. Dexter® Axle
Wheel, tire, and lug nut options for 8,000 lbs. Dexter® Axle
Description
Build this 8,000 lb. narrow overhang Dexter axle beam the way you want it. Choose the hub face, camber, spring seats, E-Z Lube, and pre-wire. Each choice is on the form. The welded-seat overhang is shorter than the standard 8,000 lb. beam. Hubs, springs, hangers, and U-bolts are not included.
Build options
- Hub face (required): 45" to 95". Maximum hub face is 95". Hub face is the measurement from the wheel mount on one hub to the same point on the other hub.
- Camber and spring seats (required): Straight, seats ship loose. Straight, seats welded on. Cambered, seats welded over the axle (overslung). Cambered, seats welded under the axle (underslung). Cambered, seats ship loose.
- Spring center (optional): Use this only if the seats are welded. Overhang is the hub face minus the spring center. It must be between 14.00" and 15.95". A 95" hub face and an 80" spring center is 15" of overhang. Leave it blank and the seats ship loose.
- E-Z Lube (required): No, or yes. Yes is an additional cost.
- Pre-wire (required): No, or yes.
Fitment note
Set the hub face between 45" and 95". If the spring seats are welded, keep the overhang between 14.00" and 15.95". Leave the spring center blank and the seats ship loose. This form does not offer a tube choice or a brake flange. This listing is the beam only. This axle is built to order. Once the order is placed it cannot be changed or returned. Verify the hub face and spring center before ordering or call for assistance.
Questions about this Dexter axle beam? Call 1-800-866-3336.
Browse more Custom Built Dexter Trailer Axles.
