Dexter® 12 ¼ Hydraulic Brake Assemblies

Genuine Dexter® 12-1/4" hydraulic brake assemblies from Southwest Wheel® are complete OEM backing-plate units for heavy-duty trailer axles from 8,000 lbs. through 15,000 lbs. Each assembly includes the backing plate, shoes and lining, wheel cylinder, springs, and hardware so you can bolt it to the axle flange and connect the brake line without rebuilding the old brake.

Dexter® 12-1/4" Hydraulic Brake Assemblies. Sold as left-hand or right-hand units. Genuine Dexter® OEM replacement parts for 12-1/4" hydraulic drums.

Key Features

• Brand: Dexter® Axle
• Type: Complete 12-1/4" hydraulic trailer brake assemblies
• Sizes: 12-1/4" x 3-3/8", 12-1/4" x 4", and 12-1/4" x 5"
• Capacity: 8,000 lbs. to 15,000 lbs. trailer axles
• Styles: Duo-servo, free-backing, parking-brake-ready, and forward self-adjusting hydraulic assemblies
• Hand: Left-hand and right-hand assemblies sold separately
• Construction: Made in the USA Dexter® OEM quality with stamped or cast backing plates, depending on axle series
• Use: Replace worn 12-1/4" hydraulic brakes on Dexter 8K, 10K HD, 12K, and 15K surge-brake or EOH axles

Match the assembly to your drum width, axle rating, bolt pattern, and left or right side. Replace brakes in pairs on the same axle so both wheels apply evenly. After installation, bleed the hydraulic system and fill the actuator with the recommended DOT 3 or DOT 4 fluid. Confirm shoe and cylinder part numbers before ordering, because 3-3/8", 4", and 5" drums are not interchangeable.

Questions about 12-1/4" Dexter hydraulic brake fitment? Call our trailer experts at 1-800-866-3336.
