Electric Trailer Brake Assemblies

Pair of 10" x 2.25" electric trailer brake assemblies with parts. 4 Hole Mounting. For Alko, Dexter, Quality, Lippert, Rockwell or other popular trailer axle manufacturers. Only works on 3,500 lbs. trailer axles with four-hole brake flange. Includes mounting hardware. These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted. The pair includes one left hand and one right hand brake assembly. Quality standards test the same as domestic backing plates.

Part No	Quantity	Description
BK-10E-01	1	10" x 2 1/4" 3.5K Electric LH
BK-10E-02	1	10" x 2 1/4" 3.5K Electric RH
716LW	8	7/16" Lock Washer
716NFN	8	7/16" Fine Nut

Left hand 10" x 2.25" electric trailer brake assembly with parts. 4 Hole Mounting.  For Alko, Dexter, Quality, Lippert, Rockwell or other popular trailer axle manufacturers.  Only works on 3,500 lbs. trailer axles with four-hole brake flange.  Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.

Part No	Quantity	Description
BK-10E-01	1	10" x 2 1/4" 3.5K Electric LH
716LW	4	7/16" Lock Washer
716NFN	4	7/16" Fine Nut

Right hand 10" x 2.25" electric trailer brake assembly with parts. 4 Hole Mounting.  For Alko, Dexter, Quality, Lippert, Rockwell or other popular trailer axle manufacturers.  Only works on 3,500 lbs. trailer axles with four-hole brake flange.  Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.

Part No	Quantity	Description
BK-10E-02	1	10" x 2 1/4" 3.5K Electric RH
716LW	4	7/16" Lock Washer
716NFN	4	7/16" Fine Nut

Pair of 10" x 2.25" Genuine Dexter electric trailer brake assemblies with parts (Dexter Part #K23-026-00 & #K23-027-00). 4 Hole Mounting. For Alko, Dexter, Quality, Lippert, Rockwell or other popular trailer axle manufacturers. Only works on 3,500 lbs trailer axles with four-hole brake flange. Includes mounting hardware. These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted. The pair includes one left hand and one right hand brake assembly. Quality standards test the same as domestic backing plates.

Part No	Quantity	Description
023-026-00	1	10" x 2 1/4" 3.5K Electric LH
023-027-00	1	10" x 2 1/4" 3.5K Electric RH
716LW	8	7/16" Lock Washer
716NFN	8	7/16" Fine Nut

Pair of 10" x 2.25" self-adjusting electric trailer brake assemblies with parts. 4 Hole Mounting. For Alko, Dexter, Quality, Lippert, Rockwell or other popular trailer axle manufacturers. Only works on 3,500 lbs. trailer axles with four-hole brake flange. Includes mounting hardware. These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted. The pair includes one left hand and one right hand brake assembly. Quality standards test the same as domestic backing plates.

Part No	Quantity	Description
BK-10E-01SA	1	10" x 2 1/4" 3.5K Electric LH Self-Adjusting
BK-10E-02SA	1	10" x 2 1/4" 3.5K Electric RH Self-Adjusting
716LW	8	7/16" Lock Washer
716NFN	8	7/16" Fine Nut

Left hand 10" x 2.25" self-adjusting electric trailer brake assembly with parts. 4 Hole Mounting.  For Alko, Dexter, Quality, Lippert, Rockwell or other popular trailer axle manufacturers.  Only works on 3,500 lbs. trailer axles with four-hole brake flange.  Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.

Part No	Quantity	Description
BK-10E-01SA	1	10" x 2 1/4" 3.5K Electric LH Self-Adjusting
716LW	4	7/16" Lock Washer
716NFN	4	7/16" Fine Nut

Right hand 10" x 2.25" self-adjusting electric trailer brake assembly with parts. 4 Hole Mounting.  For Alko, Dexter, Quality, Lippert, Rockwell or other popular trailer axle manufacturers.  Only works on 3,500 lbs. trailer axles with four-hole brake flange.  Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.

Part No	Quantity	Description
BK-10E-02SA	1	10" x 2 1/4" 3.5K Electric RH Self-Adjusting
716LW	4	7/16" Lock Washer
716NFN	4	7/16" Fine Nut

Pair of 10" x 2.25" electric trailer brake assemblies with parts. 4 Hole Mounting. Only works on 4,400 lbs Lippert trailer axles with four hole brake flange.   Includes mounting hardware. These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted. The pair includes one left hand and one right hand brake assembly. Manufactured to automotive standards in ISO/TS-16949 registered factory.  Magnets tested 100% for pull force and conductivity.  SAE rated friction material.  CSA compliant.

Left hand 10" x 2.25" 4,400 lbs. electric trailer brake assembly with parts. 4 Hole Mounting.   Only works on 4,400 lbs Lippert trailer axles with four hole brake flange.  Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.

Right hand 10" x 2.25" 4,400 lbs. electric trailer brake assembly with parts. 4 Hole Mounting. Only works on 4,400 lbs Lippert trailer axles with four hole brake flange. Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.

Pair of 12" x 2" electric brake assemblies with parts. 5 Hole Mounting.  Works with Al-Ko, Dexter, Lippert, and Rockwall Trailer Axles.  Works on 5,200 lbs. or 7,000 lbs. trailer axles with a five-hole brake flange.  Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.  The pair includes one left hand and one right hand brake assembly.

Part No	Quantity	Description
BK-12E-01	1	12" x 2" 5.2K, 6K, 7K Electric LH
BK-12E-02	1	12" x 2" 5.2K, 6K, 7K Electric RH
38LW	10	3/8" Lock Washer
38NFN	10	3/8" Fine Nut
363989	10	3/8" Mounting Stud

Left hand 12" x 2" electric brake assembly with parts. 5 Hole Mounting.  Works with Al-Ko, Dexter, Lippert, Rockwell and Quality Trailer Axles.  Works on 5,200 lbs. or 7,000 lbs. trailer axles with a five-hole brake flange.  Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.

Part No	Quantity	Description
BK-12E-01	1	12" x 2" 5.2K, 6K, 7K Electric LH
38LW	5	3/8" Lock Washer
38NFN	5	3/8" Fine Nut
363989	5	3/8" Mounting Stud

Pair of 12" x 2" Dexter electric brake assemblies with parts. 5 Hole Mounting.  Works with Al-Ko, Dexter, Lippert and Rockwall Trailer Axles.  Works on 5,200 lbs. or 7,000 lbs. trailer axles with a five-hole brake flange.  Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.  The pair includes one left hand and one right hand brake assembly.

Part No	Quantity	Description
023-180-00	1	12" x 2" 5.2K, 6K, 7K Electric LH
023-181-00	1	12" x 2" 5.2K, 6K, 7K Electric RH
38LW	10	3/8" Lock Washer
38NFN	10	3/8" Fine Nut
363989	10	3/8" Mounting Stud

Pair of 12" x 2" self-adjusting electric brake assemblies with parts. 5 Hole Mounting.  Works with Al-Ko, Dexter, Lippert, and Rockwall Trailer Axles.  Works on 5,200 lbs. or 7,000 lbs. trailer axles with a five-hole brake flange.  Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.  The pair includes one left hand and one right hand brake assembly.

Part No	Quantity	Description
BK-12E-01SA	1	12" x 2" 5.2K, 6K, 7K Electric LH Self-Adjusting
BK-12E-02SA	1	12" x 2" 5.2K, 6K, 7K Electric RH Self-Adjusting
38LW	10	3/8" Lock Washer
38NFN	10	3/8" Fine Nut
363989	10	3/8" Mounting Stud

Left hand 12" x 2" self-adjusting electric brake assembly with parts. 5 Hole Mounting.  Works with Al-Ko, Dexter, and Quality Trailer Axles.  Works on 5,200 lbs. or 7,000 lbs. trailer axles with a five-hole brake flange.  Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.

Part No	Quantity	Description
BK-12E-01SA	1	12" x 2" 5.2K, 6K, 7K Electric LH Self-Adjusting
38LW	5	3/8" Lock Washer
38NFN	5	3/8" Fine Nut
363989	5	3/8" Mounting Stud

Right hand 12" x 2" self-adjusting electric brake assembly with parts. 5 Hole Mounting.  Works with Al-Ko, Dexter, and Quality Trailer Axles.  Works on 5,200 lbs. or 7,000 lbs. trailer axles with a five-hole brake flange.  Includes mounting hardware.  These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted.

Part No	Quantity	Description
BK-12E-02SA	1	12" x 2" 5.2K, 6K, 7K Electric RH Self-Adjusting
38LW	5	3/8" Lock Washer
38NFN	5	3/8" Fine Nut
363989	5	3/8" Mounting Stud

TruRyde® Part Number BK-10KE-01 is compatible with Dexter® Part Number 023-450-00
TruRyde® Part Number BK-10KE-02 is compatible with Dexter® Part Number 023-451-00

TruRyde® Part Number BK-10KE-01 is compatible with Dexter® Part Number 023-450-00

TruRyde® Part Number BK-10KE-02 is compatible with Dexter® Part Number 023-451-00
