DeeMaxx 5,200 lb. Integral Disc Brake Kit for a Triple Axle, Maxx Calipers, Timken Bearings, Electric Over Hydraulic - DMK52IM3-TK

The DeeMaxx DMK52IM3-TK is an integral disc brake kit for a triple 5,200 lb. heavy-duty #42 axle. It covers six wheels. It is a 6 lug kit with 1/2" studs and a 12" integral rotor and hub. The calipers are Maxx finish with ceramic pads. The bearings are Timken. The kit includes six rotors and hubs DM52KROTOR, six brackets DBB-6K-MAXX, and six calipers SWCALP3-6KMAXX. The pads are SWPAD3-6KORGANIC. The kit includes the actuator TR-EOHA1600, the brake line kit DOT-TR20K, and the breakaway kit 2311-ZIP4. The kit includes the brake flange mounting stud HCS5006F020G5-ZP, the nut 38NFN, and the washer 38LW. Each rotor and hub is pre-raced and pre-studded. The stud is RTR/HUB-102-120-STUD. The kit includes the Timken bearings, the Timken seal, the caps, and the wheel nuts.

Part Number: DMK52IM3-TK, Sold as a triple kit. DeeMaxx 5,200 lb. heavy-duty integral disc brake kit for three axles with Maxx calipers, Timken bearings, and electric over hydraulic.

Product details

• Part Number: DMK52IM3-TK
• Brand: DeeMaxx
• Part type: Integral disc brake kit, triple axle, electric over hydraulic, Timken bearings
• Capacity: 5,200 lb. heavy-duty #42 axle
• Wheels: Six
• Lugs: 6 lug, 1/2" studs
• Includes rotors: Six DM52KROTOR, 12" integral rotor and hub, Maxx coating, pre-raced and pre-studded
• Stud: RTR/HUB-102-120-STUD
• Bolt circle: 6 on 5.50"
• Includes brackets: Six DBB-6K-MAXX
• Includes calipers: Six SWCALP3-6KMAXX, Maxx finish
• Includes pads: Ceramic, SWPAD3-6KORGANIC, slotted and chamfered, stainless steel clip
• Includes actuator: TR-EOHA1600, 1,600 psi
• Includes brake lines: DOT-TR20K
• Includes breakaway kit: 2311-ZIP4
• Includes mounting hardware: Brake flange mounting stud HCS5006F020G5-ZP, nut 38NFN, washer 38LW
• Includes bearings: Timken inner 25580, Timken outer 15123
• Includes seal: Timken 413470, 2.125"
• Includes caps: DC-250L with DC-RPY
• Includes wheel nuts: FA-6-080
• Bleeder: 120° bleeder
• Caliper marking: Laser writing on the caliper
• Caliper test: Every caliper is tested to 2,000 psi
• Caliper body: Ductile iron casting
• Bracket mounting: Twice as many mounting options for caliper position
• Factory: Produced in ISO quality certified factories
• Brake test: Passed the SAE J2681 brake test
• Uses spindle parts: FA-SN100, FA-SW100, FA-TW100, FA-CP175

Fitment note

This is an integral disc brake kit for a triple 5,200 lb. heavy-duty #42 axle. It covers six wheels. It is a 6 lug kit with 1/2" studs and a 12" integral rotor and hub. The bearings are Timken. The kit includes six rotors and hubs DM52KROTOR, six brackets DBB-6K-MAXX, and six calipers SWCALP3-6KMAXX. The pads are SWPAD3-6KORGANIC. The ceramic pads are slotted and chamfered and have a stainless steel clip. The actuator is TR-EOHA1600. The brake line kit is DOT-TR20K. The breakaway kit is 2311-ZIP4. The kit includes the brake flange mounting stud HCS5006F020G5-ZP, the nut 38NFN, and the washer 38LW. Each rotor and hub is pre-raced and pre-studded. The stud is RTR/HUB-102-120-STUD. The inner bearing is Timken 25580. The outer bearing is Timken 15123. The seal is Timken 413470. The cap is DC-250L with DC-RPY. The wheel nut is FA-6-080. The bleeder is 120°. The caliper has laser writing. Every caliper is tested to 2,000 psi. The caliper body is ductile iron. The bracket has twice as many mounting options for caliper position. It is produced in ISO quality certified factories and passed the SAE J2681 brake test. The spindle nut is FA-SN100. The spindle washer is FA-SW100. The tang washer is FA-TW100. The cotter pin is FA-CP175. Verify fitment before ordering or call for assistance.

Questions about this DeeMaxx kit or compatibility? Call 1-800-866-3336.
